Featuring a unique chain drive system, the Linestar has been designed to perfectly automate any sliding gate. Generally, sliding gates are used where there is limited space in an entrance, so the Linestar has been made to be the unobtrusive solution, providing highly secure, consistent operation for many years.

Automation for residential-use sliding gates with IP54 protection, equipped with:
  • self-learning of the code between transmitter and radio receiver;
  • adjustable end-stop unit in the automation;
  • control board positioned horizontally in the upper part of the gearmotor to facilitate electric cablings; completely insulated with protection cover;
  • adjustable amperometric detector that, when encountering an obstacle, reverses the movement of the wing during closure and stops it during opening;
  • coloured terminal boards to identify the various accessories and simplify the connections;
  • Signalling LEDs: power present, programming and safety tests;
  • Red LED that signals the power mains supply or green with emergency batteries inserted;
  • emergency release with personalised wrench.
ONLY £356.60 EX.VAT
£419 INC. VAT
SPECIFICATIONS
Electromechanical, 24V DC gearmotor, powered by the 230V AC control panel.
Electric panel power supply: 230V AC. - 50/60Hz
Max. absorbed power: 170W
Absorbed current: 7A max
Thrust: 300N
Max. velocity: 10 m/min
Max use frequency: 48 cycles/h with 5m gate
Operative intermittance: 50%
Reduction ratio: 1/50
Operating temperature: from -20° to +70°C
Weight: 15 kg
